32-channel Ultra AI Series IP NVR with 16 PoE

NVR7232-16P-IO-PRO

hashtag
Specifications

  • 32 IP channels

  • Video compression: H.265 and H.264

  • Simultaneous video outputs of 2 HDMI (4K) and VGA (1080P)

  • Output division: 1, 4, 9, 16, 25, 32

  • 1 input / 2 RCA audio outputs

  • Bi-directional audio

  • Audio compression: G.711a

  • Recording resolution up to 8MP (3840x2160)

  • Bandwidth: 384 Mbps in, 384 Mbps out

  • Decoding capacity:

    • 8 channels at 8MP (30 fps)

    • 32 channels 1080P (30 fps)

  • Supports adaptive decoding

  • Manual, scheduled recording modes (general, videosensor, alarm, intelligence)

  • Alarm link: Recording, Image capture, Buzzer, Log, Preset, Email

  • Supports image capture in JPEG format

  • Artificial Intelligence from intelligent cameras:

    • Perimeter protection (intrusion, line crossing).

    • Face detection

    • Object detection

    • Intelligent motion detection

  • Artificial Intelligence in the recorder:

    • Perimeter protection (intrusion, line crossing): Up to 4 channels

    • Face detection: Up to 4 channels

    • Face recognition: Up to 2 channels (20 face databases with a total of 100,000 faces)

    • Intelligent motion detection: Up to 8 channels

  • AI search by target classification (people, motorized vehicles and non-motorized vehicles)

  • Synchronized playback of up to 16 channels

  • 16 alarm inputs / 8 alarm outputs

  • Internal capacity for 2 SATA HDD up to 16TB (sold separately)

  • eSATA port

  • 16 PoE (802.3af) 10/100Mbps ports

  • 2 RJ45 Gigabit Ethernet network ports (10/100/1000Mbps)

  • Network protocols: HTTP, TCP/IP, IPv4, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, P2P, Auto register

  • Onvif and SDK support

  • Compatible with IE, Edge, Chrome, Firefox web browser

  • Compatible with Android and iOS devices

  • Communication ports: 4 USB 2.0 ports, 1 USB 3.0 port, 1 RS232 port and 1 RS485 port

  • Power supply: 110V ~ 220V AC (±10%), 47 Hz ~ 63 Hz

  • Power consumption: 20 W (excluding hard disk and PoE)

  • Operating temperature from -10°C ~ +55°C

  • Relative humidity 10%~90% (non-condensing)

  • Metal housing

  • Dimensions: 360 (W) x 48 (H) x 311.5 mm (1U)

  • Weight: 3 kg

  • Desktop installation

  • CE/FCC certified
